Contents

• About
• Features
• Installation
• Structure
• sxwm patches
• st patches
• st quirks
• Keyboard shortcuts (sxwm)
• Status bar modules (sxbar)
• Utility scripts (bin/)
• Screensaver
• Wallpaper

About

This is my personal dotfiles setup for a lightweight, keyboard-driven X11 desktop environment built around sxwm (tiling window manager, patched with a handful of local fixes — see below), sxbar (status bar), dmenu (application launcher) and st (terminal, patched with a curated set of upstream suckless patches — see below). Everything is set up automatically via install.sh — clone the repo, run the script, and you have a working environment.

Features

Installation

git clone <this repo>
cd dotfiles
./install.sh

The script installs system packages, builds and installs sxwm (with all local patches applied), sxbar, dmenu, st (with all local patches applied) and bluetui from source, installs the JetBrainsMono Nerd Font, copies config files (backing up anything that already exists), installs the utility scripts under ~/.local/bin, sets up Geany with a Gruvbox theme (see Geany below), and offers to write ~/.xinitrc for you. A couple of steps are interactive (writing ~/.xinitrc, enabling the lid-watch daemon, setting HandleLidSwitch=ignore, installing the Bluetooth no-autosuspend udev rule, Rust/bluetui, autostarting X on TTY1) so you can opt out if you already have your own setup for those.

The first question is an optional interactive WiFi setup (iwd + dhcpcd), done before the install so apt has network: it installs the two packages if missing, starts iwd, lets you pick the adapter (only asked when there's more than one), scans and lets you pick a network (or enter a hidden one), connects with iwctl, and enables dhcpcd@<adapter>.service so DHCP only runs on the adapter you chose. If dhcpcd had to be installed, the generic dhcpcd.service (all interfaces) that Debian enables is turned off again so it doesn't grab the wired interface. 802.1x (enterprise) networks aren't handled — configure those manually with iwctl.

The installer has an Omarchy-style UI: a centered logo, all the yes/no questions asked up front (one keypress each), then an unattended run with a progress bar, the current step and the tail of the log. Full output (apt, make, git, ...) goes to /tmp/dotfiles-install.log; if a step fails the log tail is shown and the script stops. ./install.sh --demo plays the UI with fake steps and touches nothing, useful for previewing or tweaking the look. Without a terminal (piped/CI) it falls back to plain ==> step lines and answers "no" to every question.

HandleLidSwitch=ignore only takes effect on the next reboot — the script deliberately doesn't restart systemd-logind live, since on this machine's manually-started (no display manager) X session that has hung the whole desktop and forced a hard reboot.

Structure

dotfiles/
├── install.sh                   # Main install script
├── BG/
│   └── j9huwdxo1zzg1.jpeg       # Desktop wallpaper
├── bin/                          # Utility scripts, installed to ~/.local/bin
│   ├── gcfs                       # Minimal gocryptfs vault manager (config-driven)
│   ├── geany                      # Wrapper: launches Geany with GTK_THEME=Gruvbox-Dark
│   ├── internal-display          # on/off/toggle/status for the internal (eDP) screen
│   ├── lid-display-watch         # Background daemon: auto internal-display on lid open/close
│   ├── lidsuspend                # Temporarily inhibit lid-close suspend
│   ├── mouse-settings            # Applies touchpad tweaks via xinput
│   ├── screensaver                # Runs random TTE animations in a loop
│   ├── screensaverd               # Idle watcher, launches the screensaver after inactivity
│   ├── screensaver-launch         # Launches the screensaver fullscreen on every monitor
│   ├── screensaver.txt            # ASCII art shown by the screensaver
│   └── status                     # Overview: WM stack, services, network, bluetooth, audio, battery, lock state
├── *.patch                       # Local sxwm patches, see "sxwm patches" below
├── st-patches/                    # Upstream st patches, see "st patches" below
│   ├── 01-delkey.patch
│   ├── 02-scrollback.patch
│   ├── 03-clipboard.patch
│   ├── 04-boxdraw.patch
│   ├── 05-vertcenter.patch
│   ├── 06-alpha.patch
│   ├── 07-blinking_cursor.patch
│   ├── 08-bold-is-not-bright.patch
│   ├── 09-anysize.patch
│   ├── 10-histsize-5000.patch
│   └── 11-kitty-graphics-protocol.patch
├── applications/
│   └── geany.desktop              # Geany launcher override (forces Gruvbox-Dark GTK theme)
├── udev/
│   └── 71-bluetooth-no-autosuspend.rules  # Opt-in: disables USB autosuspend on the BT adapter
├── themes/
│   └── Gruvbox-Dark/               # GTK3 theme, installed to ~/.local/share/themes
│       ├── index.theme
│       └── gtk-3.0/gtk.css
└── config/
    ├── sxwmrc                    # sxwm config (keybinds, layout, colours)
    ├── sxbarc                    # sxbar config (modules, colours, icons)
    ├── gcfs/
    │   └── vaults.conf            # gcfs vault list (ships with the commented example only)
    ├── geany/
    │   ├── geany.conf             # Geany prefs (Nerd Font, Gruvbox editor colour scheme)
    │   └── colorschemes/
    │       └── gruvbox.conf       # Gruvbox editor colour scheme
    └── st/
        └── config.def.h           # st config (font, colours, alpha, cursor, keybinds)

sxwm patches

install.sh clones upstream sxwm and applies these on top before building, in order:

st patches

install.sh clones upstream st (v0.9.3) and applies these on top before building, in order — all sourced from st.suckless.org/patches:

config/st/config.def.h is copied over the patched source before building, so local tweaks survive a rebuild — edit it and re-run install.sh to apply changes. It's tuned to match the previous kitty setup: Gruvbox Dark Hard colours, opaque background, steady (non-blinking) block cursor, JetBrainsMono Nerd Font, and 3 lines scrolled per mouse-wheel notch. Live font zoom is built into vanilla st — Ctrl+Shift+PageUp/PageDown to zoom, Ctrl+Shift+Home to reset — no patch needed.

install.sh also installs icat (the patch's bundled icat-mini.sh) to ~/.local/bin/icat — run icat path/to/image.png in st to display it inline.

Image protocol shortcuts (from patch 11): Ctrl+Shift+click on an image previews it in feh, Ctrl+Shift+middle-click shows placement info in less, Ctrl+Shift+F1 toggles graphics debug output, Ctrl+Shift+F6 dumps internal state, Ctrl+Shift+F7 unloads cached images to free RAM, and Ctrl+Shift+F8 toggles image display on/off entirely.

st quirks

Coming from kitty, a few things about st behave differently enough to be worth writing down:

• Config is compiled in, not read at runtime. kitty re-reads

  kitty.conf on the fly; st bakes config.def.h into the binary at build time as config.h. Changing font/colours/keybinds means editing config/st/config.def.h and rebuilding (./install.sh, or the manual steps below) — there's no config file to just edit and reopen the terminal.

• config.h doesn't auto-refresh from config.def.h. The Makefile's

  rule for config.h only runs if the file doesn't exist yet — make clean does not delete it. If you rebuild in a directory that already has a stale config.h from a previous build, your config.def.h edits are silently ignored. Either rm -f config.h before make, or always build in a fresh git clone (which is what install.sh does).

• Manual rebuild, step by step (what install.sh does for st, if you

  want to do it yourself):

  cd ~   # don't sit inside the directory you're about to rm -rf!
  rm -rf /tmp/st-build
  git clone --depth=1 https://git.suckless.org/st /tmp/st-build
  cd /tmp/st-build
  for p in ~/dotfiles/st-patches/*.patch; do patch -p1 < "$p"; done
  cp ~/dotfiles/config/st/config.def.h config.def.h
  make
  sudo make install


• Live font zoom exists but isn't advertised. Ctrl+Shift+PageUp/PageDown

  zooms the font in/out, Ctrl+Shift+Home resets it — built into vanilla st, no patch needed. Easy to miss since kitty's equivalent (change_font_size) is the one actually documented in kitty.conf.

• No runtime equivalent of kitty's per-launch --override. Things like

  window_padding_width or mouse_hide_wait are compile-time-only in st; screensaver-launch can only override font (-f) and alpha (-A) when spawning the screensaver's st instance, not padding or cursor-hiding.

• Window size is in character cells, not pixels. cols/rows in

  config.def.h set the initial size; kitty's initial_window_width/height were literal pixels. With the anysize patch the window can still be resized to any pixel size afterwards, it just doesn't start at one under sxwm anyway since sxwm tiles it immediately.

• icat needs imagemagick and bc at runtime, not just build-time

  imlib2/zlib. make succeeds without them; the script only fails the first time you actually try to display an image. Both are in install.sh's package list now.

• Scrollback is intentionally disabled inside full-screen apps (vim,

  less, tmux, etc. — anything using the alt screen). That's the 02-scrollback.patch behaviour, not a bug — those apps have their own scrolling.

• Selecting text copies to both PRIMARY and CLIPBOARD (from

  03-clipboard.patch), unlike vanilla st which only ever touches PRIMARY on select and needs an explicit keybind to push to CLIPBOARD.

Keyboard shortcuts (sxwm)

mod = Super

Media/function keys (volume, brightness, playback) are bound too — see config/sxwmrc.

Status bar modules (sxbar)

Utility scripts (bin/)

Installed to ~/.local/bin by install.sh and wired into sxwmrc/~/.xinitrc:

• mouse-settings — applies libinput touchpad tweaks via xinput (natural

  scrolling on the touchpad only, tap-to-click, etc.). Safe to re-run any time.

• internal-display [on|off|toggle|status] — (de)activates the internal

  (eDP) screen via xrandr. Refuses to turn it off if it's the only active display.

• lid-display-watch — background daemon (started via sxwm's exec) that

  watches the laptop lid state through systemd-logind and automatically turns the internal display off on lid-close / on on lid-open, provided an external monitor is connected. Opt-in during install.

• lidsuspend [on|off|status] — temporarily disables/re-enables what happens

  on lid-close (suspend), without touching /etc/systemd/logind.conf, by holding a systemd inhibitor lock.

• screensaverd — idle watcher; launches the screensaver after a period of

  inactivity (default 150 s) and kills it the moment real activity resumes.

• screensaver-launch — launches the screensaver fullscreen on every

  connected monitor.

• screensaver — runs random TTE

  (terminal text effects) animations in a loop over the ASCII art in screensaver.txt.

• status — read-only overview: which WM-stack processes and systemd

  services (bluetooth, pipewire, pipewire-pulse, wireplumber) are running, network/wifi state, connected Bluetooth devices, default audio sink, battery/AC state, DPMS/lid/lidsuspend state, and currently playing media.

• gcfs [status|mount|umount|mount-all|umount-all|add|init|edit] — minimal

  gocryptfs vault manager. Reads a name|cipherdir|mountpoint list from ~/.config/gcfs/vaults.conf, shows each vault's mount state, and mounts/unmounts by name or number (run with no args for an interactive menu). Lets gocryptfs do its own password prompt, so no secret passes through the script. Needs gocryptfs and fusermount (fuse3), both pulled in by install.sh.

Screensaver

The screensaver renders bin/screensaver.txt through random terminaltexteffects animations (installed via pipx during setup) inside a fullscreen st window, and exits the instant you touch the mouse or keyboard.

Geany

Geany is set up with a Gruvbox dark theme and JetBrainsMono Nerd Font, covering both the editor and the surrounding GTK chrome (menus, toolbar, sidebar):

• config/geany/geany.conf — editor/tagbar/msgwin

  fonts set to JetBrainsMono Nerd Font, color_scheme=gruvbox.conf.

• config/geany/colorschemes/gruvbox.conf

  — Gruvbox dark syntax colours for the editor itself.

• themes/Gruvbox-Dark/ — a GTK3 theme (Adwaita-dark's

  structure with Gruvbox colours layered on via @define-color) for the rest of the window, since Geany's own color_scheme only styles the editor pane, not the menus/toolbar/sidebar.

• bin/geany — wrapper installed to ~/.local/bin/geany that

  launches the real /usr/bin/geany with GTK_THEME=Gruvbox-Dark. A shell alias isn't enough here: dmenu/sxwm never source ~/.bashrc, but ~/.local/bin is first in PATH (see ~/.xinitrc), so the wrapper shadows the system binary for every launch path (dmenu, .desktop, terminal).

• applications/geany.desktop — copy of the

  system .desktop entry with Exec=env GTK_THEME=Gruvbox-Dark geany %F, so app-launcher entries that read .desktop files (not just $PATH) pick up the theme too.

The theme is scoped to Geany only — the system GTK theme (Adwaita) is untouched, so other GTK apps aren't affected.

Wallpaper

Set automatically via feh --bg-scale in config/sxwmrc.
